Male Thread Rod End, often referred to as rod end bearings or spherical rod ends, are mechanical parts used to connect rods or connecting rods in a variety of applications that allow for rotation and angular motion. These components feature a spherical bearing mounted in a casing with an external thread at one end. They are commonly used in mechanical, automotive applications and robotics to promote movement and adjustability.
FTM can provide a variety of standard Male Thread Rod End and a variety of special custom Male Thread Rod End, you can customize the size, accuracy, material, shape and so on
FTM Male Thread Rod End customization:
1. Accuracy level: P2,P4
2. Material selection: bearing steel, Gcr15, 45 steel, stainless steel, brass, aluminum, etc
3. Size: diameter 10mm-25mm
4. Processing technology: chamfering, drilling, threading, surface treatment (galvanizing), etc
5. Shape: Customize various shapes, according to the drawing sample customization
Load capacity:
Rod end bearings are designed to handle a variety of loads, both radial and axial. The rod ends of different materials have different bearing capacities, so the appropriate material can be customized according to the required scene.
FTM Male Thread Rod End application scenario:
Automotive: Used for suspension systems, steering components, and connections that require movement and flexibility.
Industrial equipment: Usually used in machinery that needs to convert linear motion to rotary motion.
Robotics and automation: Used in robotic arms and other automated systems to facilitate movement and positioning.
Aerospace: Used for the precise movement and adjustment of aircraft control surfaces and landing gear.
FTM Male Thread Rod End type:
Standard rod end: The basic design uses spherical bearings and external threads for a variety of applications.
Heavy-duty rod ends: Designed for high-load applications, typically with reinforced construction and materials.
Aligning rod end: The feature design allows for greater angular movement and ADAPTS to non-calibration of the connecting components.
Seal rod end: equipped with a seal to prevent contamination and maintain lubrication, extending the service life of the bearing.
Shaoxing Shangyu Flight Seiko Machinery Co., Ltd. (FTM), founded in 2006, is China Male Thread Rod End Suppliers and Wholesale Male Thread Rod End Factory.And it an enterprise focusing on the R&D, manufacturing, and customization of non-standard bearings, high-precision bearings (import substitution), and bearing accessories and mechanical parts. With more than 30 years of technical design experience, FTM has earned an excellent reputation in the field of high-quality bearings. Our professional technical team provides domestic and foreign customers with high-quality bearing solutions in engineering machinery, textile machinery, and other fields.
Relying on years of professional manufacturing and technical skills, FTM actively introduces advanced CNC machine tools from Japan to ensure product processing accuracy and stability. In addition, FTM's bearing product research is guided by a doctor of tribology. We adhere to the corporate philosophy of innovation and development, and our products are exported to many countries and regions around the world. We have long been supporting and producing various types of bearings for many world-renowned companies, maintaining good production relationships. Spin into eternity, inherit excellence, and create the future together. Choose FTM, and we will be your best choice for bearing solutions.
1. Introduction: The Unsung Heroes of Motion Ball bearings are indispensable mechanical components that play a vital, though often unseen, role in virtually every rotating machine around the globe. Th...
1. Introduction Roller bearings are a cornerstone of modern machinery. They are precision-engineered components that utilize rolling elements, such as cylinders, needles, or cones, to reduce friction ...
1. Introduction A Brief Overview of Bearings and Their Importance Have you ever wondered what allows a car's wheels to spin freely, a ceiling fan to turn smoothly, or even a hard drive to whir at incr...
As a leader in the design and manufacturing of high-quality bearings, Shaoxing Shangyu Flight Seiko Machinery Co., Ltd. (FTM) offers a comprehensive range of Male Thread Rod Ends, also known as rod end bearings or spherical rod ends. These essential mechanical components are engineered to provide a secure and flexible connection between rods and other moving parts, enabling rotational and angular motion in a wide array of applications.
Our male thread rod ends are meticulously crafted with a spherical bearing housed within a body that features a male (external) thread. This design allows for smooth, multi-directional movement while accommodating misalignment, making them indispensable in applications that require precise linkage and control. They are widely used in demanding sectors such as engineering machinery, textile machinery, automotive systems, and robotics.
With over 30 years of technical expertise, FTM stands apart through our commitment to quality, precision, and customization. We provide both standard and specialty custom Male Thread Rod Ends that meet the most rigorous industry standards.
Our customization capabilities include:
Rod ends are classified by their design, thread type, and the material of their raceway and ball. Our Male Thread Rod Ends can be designed with a variety of internal components, such as a steel-on-steel contact surface for high-load applications or a PTFE liner for maintenance-free operation. This versatility allows us to provide the perfect solution for both heavy-duty industrial environments and high-precision systems that require smooth, low-friction motion.
1. What is the difference between a male and female thread rod end?
A male thread rod end has an external thread on its body, which screws into a female (internal) threaded part. Conversely, a female thread rod end has an internal thread within its body, which screws onto a male (external) threaded part.
2. What does the P2 or P4 accuracy rating mean?
These are precision grades. P4 bearings have a higher degree of dimensional and rotational accuracy than P2 bearings, making them suitable for applications that demand extremely precise motion and minimal play.
3. How do I choose the right material for my rod end?
The choice of material depends on the application's specific requirements. Bearing steel and GCr15 are common for high strength and wear resistance. Stainless steel is ideal for corrosive environments, while aluminum is used for weight reduction. Our technical team can assist you in selecting the optimal material.
4. Can FTM produce rod ends with special coatings or treatments?
Yes. We offer various surface treatments, such as galvanizing, to enhance corrosion resistance and durability. We can also accommodate other specialized coatings or surface finishes based on customer requirements.
5. What information do I need to provide for a custom order?
For a custom order, we generally require a detailed technical drawing that specifies the dimensions (including diameter, thread type, and length), material, accuracy class, and any specific processing or surface treatment requirements. Samples are also helpful for us to replicate the exact design.
If you have any questions or would like to know more about bearings, please feel free to contact us!
